  • New GEN 2 Transmission – 50% Easier Shifting​
  • New High Output EPS – Enhanced responsiveness and slow speed maneuverability  ​
  • New 27” Pro Armor X Terrain Tires with Variable Tread Pattern for Reduced Cab Noise​
  • 24 HP Kubota Engine
  • Industry best Donaldson air filter
  • Sealed bearings and bushings
  • Heavy-duty steering rack
  • 2-piece sealed CV drive shaft
  • Mud Guards
  • Easy-Access Radiator Panel
  • Tough, One-Piece Chassis

Categories: , Tag:

Description

  • ENGINE & DRIVETRAIN

    Engine type
    Kubota 3-Cylinder Diesel
    Cylinders-Displacement (cc)
    898cc / 24.8 HP
    Transmission/Final Drive
    Automatic PVT H / L / N / R / P; Shaft
    Drive System Type
    On-Demand True AWD / 2WD / Versatrac Turf Mode. Active Descent Control (ADC) and HD features including upgraded rear driveshaft, grease nipples, HD sway bar, sealed suspensions bushings, sealed ball joints and driveshaft spline seals.
    Cooling
    Liquid

  • SUSPENSION / BRAKES / WHEELS

    Front Suspension
    Dual A-Arm with Stabilizer Bar 27.9 cm Travel
    Rear Suspension
    Dual A-Arm IRS with Stabilizer Bar 27.9 cm Travel
    Front / Rear Brakes
    Hydraulic Disc
    Parking Brake
    Hand-Actuated
    Front Tyres
    27 x 9; R12
    Rear Tyres
    27 x 11; R12
    Wheels
    14″ Alloy

  • DIMENSIONS

    Bed Box Dimensions (L x W x H)
    93.3 x 137.8 x 31.75 cm
    Front/Rear Rack or Box Capacity
    N/A / 435 kg
    Fuel Capacity
    43.5 L
    Ground Clearance
    33 cm
    Overall Vehicle Size (L x W x H)
    305 x 158 x 196 cm
    Wheelbase
    206 cm
    Estimated Dry Weight
    766 kg

  • FEATURES

    Cargo System
    Lock & Ride®
    Hitch Towing Rating
    1134 kg
    Hitch/Type
    Receiver w/ ECE R55 ball
    Instrumentation
    All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Trip Meters, Hour Meter, Gear Indicator, Fuel Gauge, Engine Temperature, Hi-Temp Light, Clock, Glow Plug Indicator, Low Oil Pressure Indicator, Seat Belt Indicator, Parking Brake Engaged Alarm, Horn, Backup Alarm
    Variants
    Homologated Tractor
    Lighting
    Headlights : halogen
